APC 1000VA Smart-UPS (SMT1000IC)

APC Smart-UPS SMT1000IC

The APC Smart-UPS SMT1000IC delivers reliable power protection for servers, network equipment, and critical electronics. This 1000VA/700W unit combines robust power management with intelligent networking capabilities through SmartConnect technology.

Advanced Power Management

The SMT1000IC provides clean, stable power with pure sine wave output. Moreover, its output voltage distortion remains below 5%, ensuring your sensitive equipment receives consistent power quality. Additionally, the unit features:

• Configurable output voltage (220V, 230V, or 240V)
• Frequency synchronization (50/60Hz ±3 Hz)
• Line interactive technology for efficient operation
• Two IEC jumper connections with battery backup

Intelligent Power Protection

Smart-UPS technology automatically adjusts to power fluctuations. The wide input voltage range (160-286V) means less battery usage, extending battery life. Furthermore, the SMT1000IC includes:

• Full-time multi-pole noise filtering
• 459 Joules surge protection
• Zero clamping response time
• UL 1449 compliant filtering

Remote Management Capabilities

The SMT1000IC features SmartConnect technology for simplified remote monitoring. Subsequently, this allows for:

• Cloud-enabled remote monitoring
• Multi-function LCD status display and control console
• SmartSlot interface for expansion cards
• Comprehensive audible alarm system with distinctive notifications

Reliable Battery Performance

The maintenance-free sealed Lead-Acid battery design ensures reliability. The SMT1000IC battery system provides:

• 3-hour typical recharge time
• Easy battery replacement (RBC6)
• Suspended electrolyte technology for leak protection

Ideal User Applications

The SMT1000IC is perfectly suited for:

• Small to medium business servers – The 700W capacity provides adequate runtime for graceful server shutdown during power outages
• Network equipment centers – Low noise operation (41dB) makes it suitable for office environments
• Point-of-sale systems – The wide input voltage range tolerates poor utility power conditions
• Healthcare monitoring equipment – Pure sine wave output ensures sensitive medical equipment operates correctly
• Security and surveillance systems – SmartConnect remote monitoring allows for unattended operation and alerts

Physical Specifications

• Height: 219.0 mm
• Width: 171.0 mm
• Depth: 439.0 mm
• Net Weight: 18.86 kg
• Color: Black

Electrical Specifications

• Output Power: 700 Watts / 1000 VA
• Nominal Output Voltage: 230V
• Input Voltage Range: 160-286V
• Input Connection: IEC-320 C14
• Waveform Type: Sine wave

Battery Specifications

• Battery Type: Maintenance-free sealed Lead-Acid
• Replacement Battery: RBC6
• Typical Recharge Time: 3 hours
• RBC Quantity: 1

Communication Features

• Interface Port: SmartSlot
• Available SmartSlot Interface: 1
• Control Panel: Multi-function LCD
• Emergency Power Off (EPO): Optional

Environmental Parameters

• Operating Temperature: 0-40°C
• Operating Humidity: 0-95%
• Operating Elevation: 0-3000 meters
• Audible Noise: 41.0 dB
• Online Thermal Dissipation: 100.000 BTU/hr

Regulatory Compliance

• Approvals: CE
• RoHS: Compliant
• REACH: Contains No SVHCs
• Other: China RoHS compliant

Warranty Information

• Standard Warranty: 3 years repair or replace (excluding battery)
• Battery Warranty: 2 years
