D-Link DGS-1100-08P 8-Port Gigabit PoE Smart Managed Switch

D-Link DGS-1100 Series Gigabit Smart Managed Switches

Versatile Networking Solution for Modern Businesses

The D-Link DGS-1100 Series represents a comprehensive range of smart managed switches designed to meet the diverse networking needs of small to medium-sized businesses. Moreover, these switches offer an intelligent blend of performance, flexibility, and energy efficiency.

Technical Innovations

Intelligent Port Management

The DGS-1100 Series provides multiple port configurations to suit various network environments. Consequently, businesses can choose from models ranging from 5 to 26 ports, with options for Power over Ethernet (PoE) support. Additionally, some models feature SFP ports for fiber connectivity, enabling expanded network infrastructure.

Advanced Surveillance Capabilities

Specifically designed for video surveillance applications, the DGS-1100 Series includes unique features such as:

• Auto Surveillance VLAN (ASV)
• ONVIF support
• PD Alive Check function
• Continuous monitoring of network topology and device status

Enhanced Security Features

Network administrators benefit from robust security mechanisms, including:

• Static MAC address filtering
• Storm Control
• Traffic segmentation
• DoS attack prevention

Ideal Users

The DGS-1100 Series is optimally suited for:

• Small and medium-sized businesses requiring flexible network management
• Organizations with video surveillance infrastructure
• Network environments demanding energy-efficient solutions
• Businesses needing scalable and manageable network switches

Specific Use Cases

• Branch offices with limited IT resources
• Educational institutions
• Retail environments
• Small enterprise network deployments
• Security and surveillance systems

Green Technology and Efficiency

Integrated D-Link Green technologies ensure:

• Reduced power consumption
• Intelligent power saving through link status monitoring
• Compliance with IEEE 802.3az Energy Efficient Ethernet standards

Management and Deployment

Network administrators appreciate the series’ management capabilities:

• Intuitive web-based GUI
• D-Link Network Assistant Utility
• Support for IPv4 and IPv6
• Simplified initial setup and configuration

Performance Specifications

Switching Capabilities

• Switching capacity ranges from 10 Gbps to 52 Gbps
• Maximum forwarding rates up to 38.69 Mpps
• MAC address table sizes from 2K to 16K entries

Power over Ethernet (PoE) Options

• PoE power budgets from 18W to 370W
• Support for 802.3af and 802.3at standards
• Up to 30W per PoE port on supported models

Reliability and Environmental Adaptability

• Operating temperature range: -5°C to 50°C
• Fanless design on most models
• Mean Time Between Failures (MTBF) up to 2,827,541 hours

Technical Specifications Overview

General Specifications

• Hardware versions: B1 and C1
• Desktop and rackmount form factors
• Port configurations: 5-26 ports
• Gigabit Ethernet support

Networking Features

• VLAN support
• Link aggregation
• IGMP snooping
• Spanning Tree Protocol
• Quality of Service (QoS)

Optional Enhancements

For extended connectivity, the series supports optional SFP transceivers:

• DEM-310GT: 1000BASE-LX, single-mode, 10 km
• DEM-311GT: 1000BASE-SX, multi-mode, 550 m

Certification and Compliance

• FCC and CE certified
• RoHS compliant
• Multiple safety certifications
