TP-Link TL-SF1009P 9-Port 10/100Mbps Desktop Switch with 8-Port PoE+

Efficient Power and Data Delivery Solution

The TL-SF1009P is a versatile 9-port Fast Ethernet switch designed to simplify network expansion while providing power to connected devices. With eight PoE+ ports supporting the IEEE 802.3af/at standard, this unmanaged switch delivers both data and power over a single cable to devices such as access points, IP cameras, and VoIP phones. The TL-SF1009P combines robust networking capabilities with intelligent power management features, making it ideal for small businesses, surveillance systems, and environments where power outlets are limited.

Advanced PoE+ Capabilities

The TL-SF1009P delivers exceptional power options for connected devices:

• Eight PoE+ ports (ports 1-8) supporting up to 30W per port
• Total PoE power budget of 65W for all connected devices
• Full IEEE 802.3af/at compliance for wide device compatibility
• Automatic detection and power delivery to compatible powered devices (PDs)
• Extended range mode for data and power transmission up to 250m
• PoE Auto Recovery feature automatically reboots unresponsive connected devices

These comprehensive PoE+ features allow for flexible deployment of powered devices without requiring nearby electrical outlets.

Intelligent Power Management

The TL-SF1009P incorporates several power management features:

• Priority Mode ensures high priority of ports 1-2 to guarantee quality for sensitive applications
• Overload protection automatically allocates power based on port priority when demand exceeds supply
• Port priority hierarchy (port 1 = port 2 = port 3 > port 4) for intelligent power allocation
• Power status indicators for monitoring connected device power usage
• Fanless design for silent operation and improved reliability

This intelligent approach to power management helps maintain network stability even under heavy loads.

Enhanced Network Performance Features

The TL-SF1009P includes specialized operational modes for improved network functionality:

• Extend Mode allows data and power transmission up to 250m for remote surveillance installations
• Isolation Mode provides one-click client traffic separation between ports 1-8 for improved security
• Auto MDI/MDIX eliminates the need for crossover cables
• Auto-negotiation selects optimal speed (10/100Mbps) for each connected device
• Store-and-forward switching prevents error propagation across the network
• 1.6Gbps switching capacity handles multiple simultaneous connections

These performance features make the TL-SF1009P suitable for a variety of networking applications, from basic connectivity to surveillance system deployment.

Simple Setup and Operation

The TL-SF1009P is designed for ease of use:

• Plug-and-play installation requires no configuration
• Desktop or wall-mountable design for flexible placement
• Compact dimensions (171 × 98 × 27 mm) conserve space
• LED indicators for Power, Link/Act, PoE Status, and PoE MAX
• Durable metal housing provides effective heat dissipation

This simplicity makes the TL-SF1009P accessible even to users with limited networking experience.

Ideal Users

The TL-SF1009P is particularly well-suited for:

• Small businesses deploying IP surveillance systems with multiple cameras
• Network administrators installing wireless access points in locations without power outlets
• VoIP deployments requiring reliable power and data connectivity
• Installations requiring extended reach for remote devices (up to 250m)
• Environments where silent operation is essential

Technical Specifications

Network Interface

• 9 × 10/100Mbps RJ45 ports
• 8 PoE+ ports (ports 1-8)
• Auto-Negotiation on all ports
• Auto-MDI/MDIX on all ports

PoE Features

• PoE Standard: IEEE 802.3af, IEEE 802.3at
• PoE Ports: 8 (ports 1-8), up to 30W per port
• PoE Power Budget: 65W total
• PoE Power Delivery: Pins 3 & 6 (Power+), Pins 1 & 2 (Power-)

Performance

• Switching Capacity: 1.6Gbps
• MAC Address Table: 2K entries with auto-learning and auto-aging
• Forwarding Mode: Store-and-forward
• Flow Control: IEEE 802.3x

Special Modes

• Extend Mode: Up to 250m transmission range (speed limited to 10Mbps)
• Priority Mode: Higher priority for ports 1-2
• Isolation Mode: Traffic separation between ports
• PoE Auto Recovery: Automatic reboot of unresponsive devices

Physical Specifications

• Dimensions (W × D × H): 6.7 × 3.9 × 1.1 in. (171 × 98 × 27 mm)
• Fanless design for silent operation
• LED Indicators: Power, Link/Act, PoE Status, PoE MAX

Power Requirements

• Max Power Consumption: 3.28W (no PD connected)
• Max Power Consumption: 74.33W (with 65W PD connected)
• Max Heat Dissipation: 11.18 BTU/h (no PD connected)
• Max Heat Dissipation: 253.47 BTU/h (with 65W PD connected)

Environmental Parameters

• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Storage Temperature: -40°C to 70°C (-40°F to 158°F)
• Operating Humidity: 10% to 90% RH, non-condensing
• Storage Humidity: 5% to 90% RH, non-condensing

Certifications

• CE
• FCC
